From materials, processes to verification, first establish a clear information structure, and then access verifiable equipment, quality and traceability data.
is not a collection of devices, But the connection of data.
Material batches, forging parameters, heat treatment curves, processing compensation and inspection results have all been reserved for display, waiting for formal manufacturing records to be accessed.
Core Capability
Ability, presented in data.
01 / FORMING6000T + 12000T + 800T
A three-level forging and molding production line consisting of 6000T, 12000T and 800T forging equipment.
Five-axis precision machining is performed on key areas such as wheel spokes, rims, and mounting surfaces. The specific machining accuracy is subject to the official engineering drawings.
The hub number is associated with material batches, production processes and inspection records. The specific traceability scope is subject to the actual system of the enterprise.
Select the process to view the manufacturing logic, quality nodes and material locations.
Process screen / 01Incoming 6061-T6 Aluminium Alloy
Current Operation / 01
Incoming Material
After the raw materials enter the factory, the grade, batch, size and appearance are inspected, and the material batch association is retained.
Documentation Status
Material and Batch Information
Quality Gates
Composition, size and appearance inspection
Traceability
Material batch association
Validation Centre
Made. Then verified.
Reserve images and reporting locations for road load, impact, size and environmental verification, and formal conclusions are released according to specific specification documents.
01 / FORMING6000T + 12000T + 800T
02 / MACHINING5-Axis Machining
03 / MEASUREMENTRunout Inspection
04 / TRACEABILITYUnique code
Radial Fatigue
Impact Testing
Engineering Drawings
Digital Records
